ED-DP

Application

ED-DP model, double flow ceiling type unit coolers, having the range 1,00 – 100,00 kW, used in commercial & industrial cold rooms and preparation rooms. The main feature of this product is the “low air flow”.

Coil Properties

ED-DP models are designed with optimum tube diameter in order to increase efficiency. Products can be provided with 4,2 and 7,0mm fin spacing. Maximum operation pressure is 25 barg.

Casework

It is manufactured with Ral 9016 electrostatic powder painted galvanized sheets to resist corrosion; it has an attractive view in addition to its rigidity.

Fan

There are blowing fans with Ø350, Ø400, Ø450 and Ø500mm diameter options. Based on the fan diameter, protection class is IP44 and IP54. Fans are compatible for ERP 2015 regulation.

Electrical Heater

High-quality electrical heaters are placed on the coil and drain pan according to working and design conditions.

Options*

Unit coolers can be provided with below options; Gold Epoxy Fins
Stainless Steel Case
EC Fan

* Please contact Karyer for option requests.

Capacity Range
